JL Audio XDM500/3

Description Product Highlights: 3-channel car/marine amplifier 75 watts RMS x 2 180 watts RMS x 1 at 4 ohms 100 watts RMS x 2 300 watts RMS x 1 at 2 ohms 200 watts RMS x 1 bridged at 4 ohms 300 watts RMS x 1 at 2 ohms front channels: variable high-pass filter (50-500 Hz, 12 dB/octave) subchannel: variable low-pass filter (50-500 Hz, 12 or 24 dB/octave) Class D amplifier design with NextD™ switching amp technology differential-balanced inputs eliminate noise coming from your vehicle’s electrical system Advanced Rollback Protection System prevents thermal shut-down Connection Features preamp inputs and outputs speaker-level inputs high-level inputs — up to 8 volts RMS (about 16 watts) DC offset or signal sensing auto turn-on eliminates the need for remote lead 4-gauge power and ground leads and a 50-amp fuse recommended — wiring and hardware not included with amplifier no onboard fuses — when installing multiple amps in a system, an additional 50-amp in-line fuse between the distribution block and the amplifier is recommended 8-9/16″W x 2″H x 7-1/8″D
